    UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug

    Ask Lasest Price
    Brand Name : ANENpower
    Model Number : APM19U
    Certification : UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
    Price : Please contact our Sales
    Payment Terms : 50% deposit, 50% before dispatch
    Supply Ability : 500,000.00pcs/month
    Delivery Time : 18~25 working days after receiving the deposit
    • Product Details
    • Company Profile

    UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug

    UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug


    The UL 60601 Certified 12V 2A Medical Grade AC Adapter is a reliable power solution designed for medical applications. With a 5V and 24V switching power supply, this adapter features a US plug for easy integration into healthcare settings.

    • Safety Certified: Complies with UL 60601 standards for medical device safety.
    • Versatile Output: Delivers stable 12V 2A power and supports 5V and 24V outputs, suitable for various healthcare devices.
    • Built-in Protection: Includes over-voltage, over-current, and short-circuit protections for safe operation.
    • Efficient Design: Optimized for high efficiency and minimal heat generation.
    • Ideal Use: Perfect for powering medical devices like diagnostic and monitoring equipment.

    This medical-grade AC adapter is essential for healthcare professionals seeking safety and reliability in their power solutions.


    • Power Range: 15~24W

    • Universal AC Input 100~240 VAC
    • Frequency: 50~60Hz
    • AC Plug type: U:USA, E:EU, K:UK, A: AU
    • Output voltage available from 5~48 VDC

    • 2 x MOPP Compliance, IEC/EN60601-1 Approval
    • LPS Compliance
    • Protections: Short circuit / Over voltage / Over current
    • Energy Efficiency Level VI
    • No Load Power Consumption ≤ 0.1W
    • MTBF > 100,000 hours
    • Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
    • All models meet RoHS and WEEE
    • Dimension(L x W x H): 60.5L x 39W x 34H(mm)
    • Weight: 120g


    Model NO.MAX OUTPUT POWEROUTPUT VOLTAGEMIN LOADMAX LOADLOAD REGULATIONLINE REGULATIONRIPPLE & NOISE
    APM19UA15W5-8V0A3.0A±5%±1%100mV
    APM19UB20W9-13V0A2.0A±5%±1%180mV
    APM19UC20W14-19V0A1.42A±5%±1%200mV
    APM19UD20W20-27V0A1.0A±5%±1%250mV
    APM19UE20W28-35V0A0.71A±5%±1%280mV
    APM19UF20W36-48V0A0.55A±5%±1%360mV
    APM19UG18W5-8V0A3.0A±5%±1%100mV
    APM19UH24W9-13V0A2.0A±5%±1%180mV
    APM19UJ24W14-19V0A1.71A±5%±1%200mV
    APM19UK24W20-27V0A1.2A±5%±1%250mV
    APM19UL24W28-35V0A0.85A±5%±1%280mV
    APM19UM24W36-48V0A0.66A±5%±1%360mV
    NOTED:
    1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
    2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
    3 : Max. Power (W) = Vo x Io
